Name: | IP67 30W 600x300 Waterproof LED Light Guide Panel for Shower Room |
Category: | IP67&IP65-600x300 LED Panel Light |
Input Voltage(V):: | AC85-265V |
Lamp Power(W):: | 30 |
Lamp Luminous Flux(lm): : | 2700 |
Lamp Luminous Efficiency(lm/w): : | 90 |
CRI (Ra>):: | 80 |
You may also be interested in below products. Click the pictures to view more:
IP67 30W 600x300 Waterproof LED Light Guide Panel for Shower Room
Specifications of Waterproof LED Panel Light 600x300:
Model No |
LM-PW603024 |
LM-PW603030 |
Power Consumption |
24 W |
30 W |
Luminous Flux (Lm) |
2160-2400 Lm |
2700-3000 Lm |
LED Qty(pcs) |
120 pcs |
150 pcs |
LED Type |
SMD 2835 |
|
Color Temperature (K) |
2800 - 7000K |
|
Color |
Warm/Natural/Cool White |
|
Dimension |
595x295x10mm |
|
Beam Angle (degree) |
>120° |
|
Light Efficiency (lm/w) |
>90lm/w |
|
CRI |
>80 |
|
Power Factor |
>0.95 |
|
Input Voltage |
AC 85V - 265V |
|
Frequency Range (Hz) |
50 - 60Hz |
|
Working Environment |
Indoor |
|
Material |
Aluminum alloy+Acrylic+PC/PS Diffuser |
|
IP Rating |
IP65 and IP67 for option |
|
Operating Temperature |
-20°~65° |
|
Dimmable |
Optional |
|
Life span |
50,000hours |
|
Warranty |
3 Years /5 Years |
What are the advantages of Lightman 600x300 Waterproof LED Panel Light?
• Superior Aluminum Alloy materials. Stylish everlasting color aluminum frame with advanced anodized and oxidation treatment. Advanced designing makes the ceiling lighting more elegant.
• Different sizes of led panel light for your options. Diversity in shape (square, rectangle)
• Easy to install. Ideal to be built into system ceilings, offices, and can be used as a suspended light fixture.
• LED panel light direct replace T8 and T5 fixtures.
• Lightman led panel light is with high efficiency, maximum uniformity by Mitsubishi light guide plate.
• The beam angle of led panel light is120°.
• Innovated structure heating design.
• EVA foam protects led panel light guide plate from reshaping.
• Constant current driver with a power factor more than 0.95;
• IP Rating is IP65 and IP67 for option.
• Waterproof Lock cable DC plug for led panel light.
• LED panel lights are CE, ROHS, FCC, TUV, GS, CB, SAA, PSE and EMC certified.
